Name: | 3A21 Aluminum Sheet |
---|---|
Name: | 3A21 Aluminum Sheet |
Model: | 3A21 |
Material: | O,H12,H14,H16 H18,H19,H22,H24 H26,H28,H112 etc. |
Thickness: | 0.2-300mm |
Width: | 100-2650mm |
Length: | 500-16000mm |
MOQ: | 5Ton |
Packaging: | Wooden box or wooden bracket |
Supply Capacity: | 5-5000tons |
Service features: | 7-45 days delivery |
Inquiry |
Brief introduction:
3A21 aluminum sheet is also a typical 3 series Al-Mn antirust alloy, but it's not difficult to sfind that it has the letter A in its name. In fact, the A here represents an improvement on the original pure aluminum, so as to develop 3A21 aluminum instead of aluminum alloy.
Applications and Features:
1. Excellent Corrosion Resistance. The 3A21 aluminum sheet is close to the corrosion resistance of industrial pure aluminum, has good corrosion resistance to atmosphere, fresh water, seawater and some acids, etc.
2. Better Plasticity. The plasticity of 3A21 aluminum alloy is very high in the annealing state, good in the case of semi-cold hardening, and low in the case of cold hardening.
3. Good Weldability. 3A21 aluminum sheet has good spot welding, gas welding, argon arc welding and other welding effects.
4. Mechnical Properties. 3A21 aluminum sheet tensile strength σb (MPa) is 120-160, conditional yield strength σ0.2 (MPa)≥8, elongation δ10≤2%.
The Use of 3A21 Aluminum Sheet:
1. Low load parts for working in liquid or gaseous medium. Such as Oil tanks, Gasoline, Lubricating oil pipes, Various liquid containers, and other small load parts made by deep drawing.
2. For use under conditions of higher strength than 1 series alloy. Such as Kitchen utensils, Food/chemical products processing and storage equipment, Transport tank of liquid products, Thin plate for all kinds of pressure vessels and pipe, Brazed plate-type heat exchanger, Insulation equipment, Cosmetic board, Photocopying machine drum, Marine tread plate. As for wire is used for rivets.
